Video Solutions Dual Channel MPEG2/4 Encoder with CVBS/SDI Inputs
Description
Click to rate this post!
[Total: 0 Average: 0]
Video Solutions Dual Channel MPEG2/4 Encoder with CVBS/SDI Inputs
Video Solutions Dual Channel MPEG2/4 Encoder is intended for real time encoding of CVBS or SDHD SDI signals into MPEG-2 SD or MPEG-4(H.284) SDHD format. Each channel can have two Transport Streams (TS).
One of the two TS provides high resolution (1920×1080 or less) for high quality broadcasting, the other TS provides low resolution (320×240 or less) for broadcasting to mobile devices or internet. The Encoder enables multiplexing of the four TS onto any of the two ASI outputs or any of the four IP addresses.
Built-in multiplexer: each output can be configured to carry either a Single Program Transport Stream (SPTS) or a Multi Program Transport Stream (MPTS).
Specifications
Click to rate this post!
[Total: 0 Average: 0]
|
Video Inputs
|
|
|---|---|
|
Analogue Input
|
two Composite (BNC (75ohm))
|
|
Level
|
1000mvp-p
|
|
Digital Input
|
two SDI, BNC (75ohm))
|
|
Level
|
800mVp-p
|
|
Aspect Ratio
|
4:3, 16:9
|
|
Audio Input
|
|
|
Analogue Input:
|
2 Stereo (4 Channels, XLR)
|
|
Frequency Range
|
20Hz-20kHz
|
|
Impedance
|
600ohm / 0kohm
|
|
Digital Input
|
Embedded SDI
|
|
Sampling Rate
|
48 kHz
|
|
Video Encoder
|
|
|
Encoding
|
MPEG 2 HP@HL, MP@HL, MP@ML.
MPEG 4 H.264 HP@L4, MP@L3 |
|
Encoding Rate
|
0,5 ~ 15Mbps
|
|
Chroma Format
|
4:2:0
|
|
Bit Rate Mode
|
CBR, VBR
|
|
Audio Encoder
|
|
|
Sampling Rate
|
48 kHz
|
|
MPEG 1 Layer II 64 – 320 Kbps
|
|
|
TS Output
|
|
|
Transport Stream
|
ASI 2 port
|
|
Connector
|
BNC (75 Ohm)
|
|
TS Bit Rate
|
0,5 ~ 15 Mbps
|
|
Packet Format
|
188 Byte
|
|
IP TS Output and Ethernet Control
|
|
|
Ethernet Type
|
10/100 Base-T (RJ-45)
|
|
Format
|
UDPIP, RTPIP
|
|
IP Address Format
|
Multicast, Unicast
|
|
TS Bit Rate
|
0,5 ~ 15 Mbps
|
|
TS Packet Format
|
188 Byte
|
|
Genereal
|
|
|
Power Supply
|
220V -20%
|
|
Power Consumption
|
Max 10 W
|
|
Size
|
19′, 1U 480 x 45 x 180 mm
|
|
Weight
|
3kg
|
