Panasonic TH-86EQ1 4K LED LCD Display

SKU: TH-86EQ1 Category:
Description
Click to rate this post!
[Total: 0 Average: 0]

Panasonic TH-86EQ1 86″ 4K Entry Level Digital Display

Panasonic TH-86EQ1 is a 86″ 4K professional entry-level digital display with a thin and stylish design offering high-level digital signage with easy installation and high connectivity. Ideal for corporate and retail environments. Panasonic TH-86EQ1 includes Remote Control – Batteries (AAA size) x 2, 4-pole mini plug conversion cable – AC cord (approx. 2.0 m (79″)), Clamper x 3 – USB Memory cover x 1, CD-ROM / User Manual – Operating Instruction Book.

Features:

  • 86″, 350 cd/m²
  • 4k Ultra HD resolution delivering the highest detail and image quality. Non-4K sources are also beautifully compensated.
  • Simple signage with a built-in USB media player. Synchronized playback on multiple displays via USB and LAN.
  • Extensive connectivity features. 4K/60p video input signals via 2 x HDMI. Supports CEC over HDMI® for power on/off.
  • Easy setup and safe operation. Failover and Failback function for any unexpected troubles. Monitoring of multi-displays can be done through the free Multi Monitoring & Control software.

Convenient for Video Conferences

Cisco Systems can be connected. The power supply for the display can be turned on and off by the Cisco Systems Device Controller. Or when connected to a Cisco Systems device, the video mode, video conference mode, etc., can be automatically set.

Specifications
Click to rate this post!
[Total: 0 Average: 0]

Product Specifications

Specification Description
Screen size (diagonal) (inch) 86-inch
Screen size (diagonal) (mm) 2174 mm
Aspect Ratio 16:9
Panel Type IPS Panel / E-LED
Effective display area (W x H) (mm) 1895 x 1065 mm
Effective display area (W x H) (inch) 74.6 x 41.9 inch
Resolution 3840 x 2160
Brightness (Typ.) 350 cd/m2
Contrast Ratio 1200: 1
Response Time 8 ms (G to G)
Terminals | HDMI IN HDMI TYPE-A Connector x 2 (HDCP2.2 supported)
Terminals | DVI-D IN/AUDIO IN (L/R) DVI-D 24-pin x 1, DVI Revision 1.0 Compatible (HDCP 1.1 supported) / Stereo Mini Jack (M3) x 1 (Shared with Video/PC In)
Terminals | PC IN/AUDIO IN (L/R) Mini D-sub 15-pin x 1 (Compatible with DDC 2B) / Stereo Mini Jack (M3) x 1 (Shared with Video/DVI-D In)
Terminals | USB USB Connector (TYPE A) x 1, DC 5 V/2 A (USB 3.0 supported)
Terminals | Serial D-sub 9-pin x 1 (Input), RS-232C Compatible
Terminals | LAN RJ45 x 1, 10BASE-T/100BASE-TX/1000BASE-T, Compatible with PJLink™
Terminals | IR In/Out Stereo Mini Jack (M3) x 1 / x 1
Built-in Speaker 20 W [10 W + 10 W]
Power Requirements 110-127 V AC, 50/60 Hz, 220-240 V AC, 50/60 Hz
Power consumption 363 W
Power Off Condition Approx. 0.3 W
Standby Condition Approx. 0.5 W
Dimensions (W x H x D) (mm) 1928 x 1099 x 86 mm
Dimensions (W x H x D) (inch) 76.0 x 43.3 x 3.4 inch
Bezel width (mm) 15.2 mm (all)
Bezel width (inch) 0.60 inch (all)
Weight (kg) Approx. 66 kg
Weight (lbs.) 145.5 lbs.
Wall-hanging pitch (mm) 600 x 400 mm VESA Compliant
Wall-hanging pitch (inch) 23.6 x 15.8 inch VESA Compliant
Orientation Landscape/Portrait
Tilting angle 0-20 degrees forward/backward with landscape/portrait setting
Operating environment 0°C to 40°C (32°F to 104°F) / for up to 1400 m (4593 ft) altitude,0°C to 35°C (32°F to 95°F) / Altitude 1400-2800 m [4593 ft to 9186 ft]
Operating Time 24 h/day
Viewing angle [(T/B)/(L/R)] 178° / 178° (CR≧10)
Terminals | AUDIO OUT Stereo Mini Jack (M3) x 1 / Variable Output (-∞ – 0 dB) (at 1 kHz 0 dB Input, 10 kΩ Loaded)
Terminals | Video/AV In 4-pole Mini Jack (M3) x 1 (Audio: Stereo Mini Jack (M3) x 1(Shared with DVI-D/PC In))
Panel Surface Treatment Anti-glare type (Haze 28%)
